Schenck process Intecont Plus Belt Weigher User Manual

Function Distributor
The function distributor lets you call further functions,
or dialogs.
G Call function distributor.
If no event is available, display shows
function selected last.
f Start function.
N Return to normal display and/or
abort function.
TU Scroll through function distributor
Display Events E
Test Display
START/STOP Prefeeder Z
Service Values
Batch Number B
Print Counter Readings
>0< Zero Set
START/STOP Keyboard Mode
Activate/Deactivate EasyServe
Programming
Calibrating Functions S
Read Parameters
Enter Parameters S
Load Default Parameters S
Print Parameters
Status Report
Tare S
START/STOP Simulation
Check Weight S
Imp/Belt Circuit S
Set Time S
Programming and calibrating functions lead to further
menus you can move through using cursor keys.
B = If batching mode is selected, you can access
additional functions in main distributor.
Abort Batch
Deselect Batch
Batch Number
Print Batch
Make-up
Next = Belt Empty
S = Calibrating functions protected by password.
Prompt is output after call of function.
E = If an event is available
Z = Iif activated via parameter
Moving through function distributor has no effect on
weighing functions.
Display Test and Version Number
Lets you check displays and signal lamps.
G
TU
f
Call display test.
1. Display elements flash
rhythmically.
2. Version number is displayed for
apr. 3 s.
Test terminates automatically.
Example:
VBW : Belt Weigher
20600-00 : Version number
0837
VBW INTECONT PLUS
Control
BV-H2214 GB 8
Technische
Redaktion PDE-RD
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
Function
Display Events
INTECONT PLUS
VBW 20600-00 2482
