Parameters Overview
This list applies to software: VBW 20600-08
Block A Dialog Behaviour
A 01 Language ENGLISH
A 02 Units SI
A 03 Password 07734 or 7734)
A 04 2.Password 2889
A 05 Feeder ON/OFF active
A 06 Keyb. Mode ON/OFF active
A 07 Batch ON/OFF active
A 08 >0: Zero ON/OF active
A 09 EasyServe ON/OFF active
A 10 Totalizer1 ON/OFF active
A 11 Totalizer2 ON/OFF active
Block B Rated Data
B 01 Feed Rate Unit —- t/h
B 02 Nominal Feed Rate 400,0000 t/h
B 03 Tacho Source DI I+, DI7 HI
B 04 vs Charact. Value 50.26 I/m
B 05 Nominal Speed 1,0000 m/s
B 06 START Source OP
B 07 FMZ1 Unit —— t
B 08 FMZ1 Pulse Dur. 0 ms
B 09 FMZ2 Unit —— t
B 10 FMZ3 Unit —— t
B11 DO Pulse Counter —
B12 Pulse Weighting 0.0 kg
Block C Calibrating Data
C 01 Belt Circuit No. 1.00
C 02 Belt Circuit Time 30.0 s
C 03 L/C Charac. Value 2,8500 mV/V
C 04 L/C Rated Cap. 220,000 kg
C 05 Eff. Platf. Length 1,000 m
C 06 Lever Ratio 1,0000
C 07 Angle a 0.0 degrees
C 08 Check Weight 50,000 kg
Block D Calibrat. Results
D 01 Nominal Belt Load 111,11 kg/m
D 02 Span Correction 1,0000
D 03 Total Tare 0,00 kg/m
D 04 Basic Tare N 0,00 kg/m
D 05 Tare Correction T 0,00 kg/m
D 06 Belt Circuit Char 1000 000 I/B
Block E Analog Output
E 01 Elevation AO1 I
E 02 Elevation AO1 4,00 mA
E 03 Limit Value AO1 20,00 mA
E 04 Source AO2 Q
E 05 Elevation AO2 4.00 mA
E 06 Limit Value AO2 20.00 mA
Block F Limit Values
F 01 Value for I-MIN 5,0 %I
F 02 Event Class I-MIN WARNING 2
F 03 Value for I-MAX 120,0 %I
F 04 Event Class I-MAX WARNING 2
F 05 Value for Q-MIN 20,0 %Q
F 06 Event Class Q-MIN WARNING 2
F 07 Value for Q-MAX 120,0 %Q
F 08 Event Class Q-MAX WARNING 2
F 09 Value for V-MIN 5,0 %V
F 10 Event Class V-MIN WARNING 2
F 11 Value for V-MAX 120,0 %V
F 12 Event Class V-MAX WARNING 2
Block G Filter Setting
G 01 I Display 3,0 s
G 02 I Analog Output 3,0 s
G 03 Q Display 3,0 s
G 04 V Display 3,0 s
G 05 L/C Filter 1,0 s
G 06 Afterfl. Time 3,0 s
Block H AUTO Zero Set
H 01 AUTO Zero Active NO
H 02 Limit Value Diff. 0,50 %Q
H 03 Mean Limit Value 1,00 %Q
H 04 Zero Set Limit 5,00 %Q
H 05 Tare Corr. > MAX WARNING 1
H 06 Zero Set Time 4 h
H 07 Time Elapsed IGNORE
H 08 Print Result NO
H 09 ZDO Active NO
H 10 ZDO Limit 1,00 %Q
H 11 Zero Set Diff. 5,0 %
H 12 Tare Diff. >MAX WARNING 2
0837
VBW INTECONT PLUS
Parameterization
BV-H2214 GB 46
Technische
Redaktion PDE-RD
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
