Block I Batch Mode
I 01 Batch Dribble FD 100,000 kg
I 02 Batch End 0,000 kg
I 03 Adaption Fact. 1,0
I 04 Batch Tolerance + 1,0 %
I 05 Batch Tolerance - 1,0 %
I 06 Out of Tolerance WARNING 1
I 07 Belt Empty NO
I 08 Batch > Setp. IGNORE
I 09 Batch Source OP
Block J Printer Setting
J 01 Baud Rate 9600
J 02 AUTO Print NO
J 03 Print Subtotal Error
J 04 Reset Print FMZ 1 NO
J 05 Reset Print FMZ 2 NO
J 06 Print Page Length 72 lines
J 07 Batch Setp.Line 6
J 08 Batch Setp.Col. 8
J 09 Batch Act.Line 7
J 10 Batch Act.Col. 8
J 11 FMZ 1 Line 8
J 12 FMZ 1 Column 8
J 13 FMZ 2 Line 9
J 14 FMZ 2 Column 8
J 15 Date/Time Line 4
J 16 Date/Time Column 8
J 17 Event Line 12
J 18 Event Column 8
J 19 Set Line to Zero 10
J 20 Set Column to Zero 8
J 21 Line Number 3
J 22 Column Number 8
Block K Maintenance Int.
K 01 Maintenance Elec. 3000 hours
K 02 Event Maint. EL. WARNING 1
K 03 Maint. STR-Meter 3000 hours
K 04 Event Maint. Run. WARNING 1
K 05 SPC Time 8 hrs
K 06 SPC Filter 1,00 hour
BLOCK L Comm. Fieldbus
L 01 Protocol Type NO
L 02 Host timeout 5 s
L 03 Comm.-Error Host ALARM (S 09)
L 04 Word sequence I:std/L:std
L 05 Byte sequence Low-High
L 06 Configuration FIXED
L 07 Address 1
L 08 Resolution 4096
L 09 Physics RS 485
L 10 Baud Rate 9600
L 11 Format Data 8-E-1
L 12 Adresse 16
L 13 FLOAT-Format IEEE
L 14 Address 63
L 15 Baud Rate 125K
L 17 S5 Physics RS422
L 22 Hardware VxB020
Block M Feeder Control
M 01 Feeder Active NO
M 02 Setting Time 0,0 s
M 03 Feed Distance 0,00 m
M 04 Motor STOP aft. ST NO
M 05 Change-over FF/DF YES
Block N Scale Monitoring
N 01 CPD Active NO
N 02 Platf.Dis.Length 0,00 %LB
N 03 Belt Sensor Active NO
N 04 Source Sensor DI6
N 05 BIC Active NO
N 06 Sensor Length 8.20cm
N 07 Sensor Width 12.00 cm
N 08 Sensor Offset 0.00 cm
N 09 Belt Drift 3.00 cm
N 10 Belt Drift Event W1 (C04)
N 11 Belt Skew 4.00cm
N 12 Belt Skew Event A (C03)
N 13 Slip Limit 2.00 %LB
N 14 Slip Event W1 (C08)
N 15 DO Belt Drift —
N 16 DO Belt Skew —
N 17 DO Slip —
N 18 Freeze BIC —
Block O Events
O 01 Power Failure A (E01)
O 02 Memory Error A (S01)
O 03 Tacho Input A (C02)
O 04 Namur Err. Tacho A (E02)
O 05 Namur Err Belt W1 (E03)
O 06 L/C Input A (C01)
O 07 No Release W1 (S02)
O 08 L/C Input > MAX A (H04)
O 09 L/C Input < MIN A (L04)
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 47
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
