O10 Simualtion Active W2 (S07)
O11 Error Ext. Event A (E06)
Block P Digital Inputs
P 01 Release DI I+ DI 3 HI
P 02 Stop Batch —
P 03 Ackn. Events DI I+DI1 HI
P 04 DI Start —
P 05 DI Setting to zero —
P 06 DI Ext. Event —
Block Q Digital Outputs
Q 01 DO Alarm DO I+ D03 LO
Q 02 DO Prefeeder ON —
Q 03 DO Feeder ON DO I+ D01 HI
Q 04 DO I-MIN DO I+ DO4 LO
Q 05 DO I-MAX DO I+ DO2 LO
Q 06 DO Q-MIN —
Q 07 DO Q-MAX —
Q 08 DO v-MIN —
Q 09 v-MAX —
Q 10 DO Batch Active —
Q 11 DO Full Feed —
Q 12 DO Dribble Feed —
Q 13 DO Keyboard Mode —
Block R Comm. EasyServe
R 01 Station Address 1
R 02 Physics RS 232
R 03 EasyServe Baudr. 19200
R 04 Format Data 8-0-1
R 05 Connection serial
R 06 MODBUS Idle Time 4ms
Block S: Secondary display DLZ
S01 DLZ active No
S02 Baud rate 9600
S02 Data format 8 bit NO
S04 Physics RS232
Block U: Ethernet
U 01 IP-Address 1 192
U 02 IP-Address 2 168
U 03 IP-Address 3 240
U 04 IP-Address 4 1
U 05 Net Mask 1 255
U 06 Net Mask 2 255
U 07 Net Mask 3 255
U 08 Net Mask 4 0
U 09 Gatway 1 192
U 10 Gatway 2 168
U 11 Gatway 3 240
U 12 Gatway 4 0
BLOCK V: Fixmode Parameter
V 01 ID Preset Value 1 320
V 02 ID Preset Value 2 352
V 03 ID Preset Value 3 384
V 04 ID Preset Value 4 596
V 05 ID Preset Value 5 594
V 06 ID Preset Value 6 598
V 07 ID Preset Value 7 0
V 08 ID Preset Value 8 0
V 09 ID Read Value 1 752
V 10 ID Read Value 2 784
V 11 ID Read Value 3 1552
V 12 ID Read Value 4 1872
V 13 ID Read Value 5 1874
V 14 ID Read Value 6 1880
V 15 ID Read Value 7 1884
V 16 ID Read Value 8 1876
0837
VBW INTECONT PLUS
Parameterization
BV-H2214 GB 48
Technische
Redaktion PDE-RD
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
