Schenck process Intecont Plus Belt Weigher User Manual

Start and Abort
g Start batch, process starts.
Display ZI moves from 0 towards
setpoint
Display Zd moves from setpoint
towards 0.
B Abort batch.
Batching continues upon next start
command.
Deselect Batch
Lets you deselect batching mode, i.e. mode is removed
from active functions available.
Totals sign disappears from upper display, batching
values ZI, Zd, Zb and Nb are no longer available, but
remain stored.
Prerequisites : Batch complete, or aborted using
“Abort Batch” function; scale OFF.
GT
f
Call function distributor,
select “Deselect Batch” function,
and acknowledge.
Use “Select Batch” function to reactivate batching
mode.
Old values ZI, Zd, Zb and Nb can be viewed again.
Abort Batch
This function lets you abort a running batch, i.e.
batching immediately stops.
Batching mode remains selected.
New batch starts upon next start command, old batch
is not resumed.
Use “Make-up” function to complete old batch.
GT Call function distributor and select
“Abort Batch” function.
f Acknowledge.
You can also abort batch using the P02 contact.
Make-up
Lets you add a selected amount of material to a batch
aborted or complete.
Prerequisites : Running batch complete, scale OFF.
No batch printout.
Display ZI : Batch actual setpoint resumes from
achieved value.
Display Zd : Batch residual value remains
unchanged.
Display Zbn : Make-up setpoint
Display Zdn : Batch residual value of make-up
amount
Zdn = Zbn - make-up amount
already fed.
You can scroll all displays into lower display field
using cursor keys.
Zdn and Zbn are available only until start of next
batch.
GT Call function distributor and select
“Make-up” function.
f Acknowledge.
System prompts for input of
make-up setpoint Zbn in kg or t.
The units is that of Counter 1.
P Until start of make-up, setpoint Zbn
can be changed.
gB Start or abort make-up
If make-up batch is complete, normal batch starts
upon next start command.
For new make-up, call function again.
“Abort Batch” function also aborts make-up
operations.
0837
VBW INTECONT PLUS
Control
BV-H2214 GB 10
Technische
Redaktion PDE-RD
Transmission to third parties and reproduction of
this documentation are not permitted. Schenck
Process GmbH reserves all rights of ownership
and copyrights.
