Block B : Rated Data
B01 Feed Rate Unit
Range: ------ t/h
----.- t/h
---.-- t/h
--.--- t/h
------ kg/h
----.- kg/h
- - -. - - kg/h
- -.- - - kg/h
Default:------t/h
Determine feed rate display format.
B02 Nominal Feed Rate
Range: 0,0020...99999,9 t/h Default: 400,0000 t/h
Reference for limit values and service displays
B03 Tacho Source
Range: DI
—
Default: DI I+ DI7 HI
Select - to stop belt speed measurement.
Computation uses nominal speed B 05.
B04 vs Charact. Val.
Range: 10,00...100 000,0 I/m Default:
50,26 I/m
Number of speed transducer pulses per belt meter.
Product B 04*B05must range between 0.5...2500
Hz of speed input.
Special case:B 03 = NO
Do not change characteristic value vs; this
would change the run time of your setting
programs.
B05 Nominal Speed
Range: 0,0100...10,000 m/s Default: 1,0000 m/s
Limit value reference.
If BIC or CPD (Parameter Block N) are used, value
should be accurate to some percent.
If scales operate without speed measurement, B 05
determines the accuracy.
B06 START Source
Range: OP
FB
DI
v
Default: OP
To start/stop totalization, there is no single solution:
OP : from INTECONT keyboard
FB : via fieldbus interface
DI : using digital input. Default value is DI2. You
can also use any other free digital input.
Digital input operates edge-controlled, i.e. if
scale fails after Alarm, remove START signal
and re-apply.
v : If you select belt speed “v”, totalization starts at
v>v-min (Parameter F09) and stops at
v<v-min.
0837
INTECONT PLUS VBW
Parameterization
BV-H2214 GB 51
Transmission to third parties and reproduction of
this documentation are not permitted.
SchenckProcess GmbH reserves all rights of
ownership and copyrights.
Technische
Redaktion PDE-RD
