Date _______________
Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
SET.33
of 35
SEL-387-0, -5, -6 Relay Settings Sheets
Port Settings (SET P Command)
Port Settings (SET P Command)
NOTE: RTSCTS setting does not appear if PROTO = LMD or DNP. LMD PREFIX, ADDR, and SETTLE do
not appear if PROTO = SEL or DNP. See Appendix C: SEL Distributed Port Switch Protocol (LMD) for
details on LMD protocol and see Appendix G: Distributed Network Protocol for details on DNP
protocol.
Port 1 (SET P 1) Rear Panel, EIA-485 Plus IRIG-B
Port Protocol (SEL, LMD, DNP)
[RTDA, RTDB for SEL-387-5 and SEL-387-6 Relays only]
PROTO =
LMD Prefix (@, #, $, %, &)
PREFIX =
LMD Address (1–99)
ADDR =
LMD Settling Time (0–30 seconds)
SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200)
SPEED =
Data Bits (7, 8)
BITS =
Parity Odd, Even, or None (O, E, N)
PARITY =
Stop Bits (1, 2)
STOP =
Time-out (for inactivity) (0–30 minutes)
T_OUT =
Send auto messages to port (Y, N)
AUTO =
Enable hardware handshaking (Y, N)
RTSCTS =
Fast Operate Enable (Y, N)
FASTO P =
Port 2 (SET P 2) Rear Panel, EIA-232 With IRIG-B
Port Protocol (SEL, LMD, DNP)
[RTDA, RTDB for SEL-387-5 and SEL-387-6 Relays only]
PROTO =
LMD Prefix (@, #, $, %, &)
PREFIX =
LMD Address (1–99)
ADDR =
LMD Settling Time (0–30 seconds)
SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200)
SPEED =
Data Bits (7, 8)
BITS =
Parity Odd, Even, or None (O, E, N)
PARITY =
Stop Bits (1, 2)
STOP =
Time-out (for inactivity) (0–30 minutes)
T_OUT =
Send auto messages to port (Y, N)
AUTO =
Enable hardware handshaking (Y, N)
RTSCTS =
Fast Operate Enable (Y, N)
FASTO P =
