SEL-387-0, -5, -6 Relay Settings Sheets
Port Settings (SET P Command)
SEL-387-0, -5, -6 Relay Instruction Manual Date Code 20170601
Date________________
Port 3 (SET P 3) Rear Panel, EIA-232
Port Protocol (SEL, LMD, DNP)
[RTDA, RTDB for SEL-387-5 andSEL-387-6 Relays only]
PROTO =
LMD Prefix (@, #, $, %, &)
PREFIX =
LMD Address (1–99)
ADDR =
LMD Settling Time (0–30 seconds)
SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200)
SPEED =
Data Bits (7, 8)
BITS =
Parity Odd, Even, or None (O, E, N)
PARITY =
Stop Bits (1, 2)
STOP =
Time-out (for inactivity) (0–30 minutes)
T_OUT =
Send auto messages to port (Y, N)
AUTO =
Enable hardware handshaking (Y, N)
RTSCTS =
Fast Operate Enable (Y, N)
FASTO P =
Port 4 (SET P 4) Front Panel, EIA-232
Port Protocol (SEL, LMD, DNP)
[RTDA, RTDB for SEL-387-5 and SEL-387-6 Relays only]
PROTO =
LMD Prefix (@, #, $, %, &)
PREFIX =
LMD Address (1–99)
ADDR =
LMD Settling Time (0–30 seconds)
SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200)
SPEED =
Data Bits (7, 8)
BITS =
Parity Odd, Even, or None (O, E, N)
PARITY =
Stop Bits (1, 2)
STOP =
Time-out (for inactivity) (0–30 minutes)
T_OUT =
Send auto messages to port (Y, N)
AUTO =
Enable hardware handshaking (Y, N)
RTSCTS =
Fast Operate Enable (Y, N)
FASTO P =
Port N (SET P N), EIA-232 for PROTO = RTDA
(SEL-387-5 and SEL-387-6 Relays only)
Number of RTDA (0–12)
RTDNUMA =
RTD 1A Type (NA, PT100, NI100, NI120, CU10)
RTD1TA =
