Date _______________
Date Code 20170601 Instruction Manual SEL-387-0, -5, -6 Relay
SET.35
of 35
SEL-387-0, -5, -6 Relay Settings Sheets
Port Settings (SET P Command)
RTD 2A Type (NA, PT100, NI100, NI120, CU10) RTD2TA =
RTD 3A Type (NA, PT100, NI100, NI120, CU10)
RTD3TA =
RTD 4A Type (NA, PT100, NI100, NI120, CU10)
RTD4TA =
RTD 5A Type (NA, PT100, NI100, NI120, CU10)
RTD5TA =
RTD 6A Type (NA, PT100, NI100, NI120, CU10)
RTD6TA =
RTD 7A Type (NA, PT100, NI100, NI120, CU10)
RTD7TA =
RTD 8A Type (NA, PT100, NI100, NI120, CU10)
RTD8TA =
RTD 9A Type (NA, PT100, NI100, NI120, CU10)
RTD9TA =
RTD 10A Type (NA, PT100, NI100, NI120, CU10)
RTD10TA =
RTD 11A Type (NA, PT100, NI100, NI120, CU10)
RTD11TA =
RTD 12A Type (NA, PT100, NI100, NI120, CU10)
RTD12TA =
Port N (SET P N), EIA-232 for PROTO = RTDB
(SEL-387-5 and SEL-387-6 Relays only)
Number of RTDB (0–12)
RTDNUMB =
RTD 1B Type (NA, PT100, NI100, NI120, CU10)
RTD1TB =
RTD 2B Type (NA, PT100, NI100, NI120, CU10)
RTD2TB =
RTD 3B Type (NA, PT100, NI100, NI120, CU10)
RTD3TB =
RTD 4B Type (NA, PT100, NI100, NI120, CU10)
RTD4TB =
RTD 5B Type (NA, PT100, NI100, NI120, CU10)
RTD5TB =
RTD 6B Type (NA, PT100, NI100, NI120, CU10)
RTD6TB =
RTD 7B Type (NA, PT100, NI100, NI120, CU10)
RTD7TB =
RTD 8B Type (NA, PT100, NI100, NI120, CU10)
RTD8TB =
RTD 9B Type (NA, PT100, NI100, NI120, CU10)
RTD9TB =
RTD 10B Type (NA, PT100, NI100, NI120, CU10)
RTD10TB =
RTD 11B Type (NA, PT100, NI100, NI120, CU10)
RTD11TB =
RTD 12B Type (NA, PT100, NI100, NI120, CU10)
RTD12TB =
