Compressed ASCII Commands
SEL-387-6 Relay
CTH Event Report
If no parameters are specified on the command line, all archived thermal event
reports are displayed. To obtain thermal event reports, send the following:
CTH <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"Event#","Phase","MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","Load Cond","Cool
Sys","Load","Ambient","Calc TopOil","Msrd TopOil","Hot Spot",
"FAA","RLOL","TLOL","TLL","yyyy"<CR>
x,x,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,,"xxxxxx","xxxxxxxxx",xxxx,xxxx,xxxx,xxxx,xxxx,xxx
x,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archived events are listed)
<ETX>
If no data are available, the relay replies:
"No Data Available","0668"<CR>
CTH Daily Profile
Data Report
If D is specified in the command line, the report on daily profile data is
provided. To obtain the report for Phase A, send the following:
CTH D 1 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"MONTH_","DAY_","YEAR_","Ambient","Calc TopOil","Msrd TopOil","Hot Spot","Load",
"Max FAA","RLOL","TLOL",,"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
To obtain the report for Phase B, send the following:
CTH D 2 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"MONTH_","DAY_","YEAR_","Ambient","Calc TopOil","Msrd TopOil","Hot Spot","Load",
"Max FAA","RLOL","TLOL",,"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
To obtain the report for Phase C, send the following:
CTH D 3 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"MONTH_","DAY_","YEAR_","Ambient","Calc TopOil","Msrd TopOil","Hot Spot","Load",
"Max FAA","RLOL","TLOL",,"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
where:
xxxx = data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the checksum for the
line.
