Compressed ASCII Commands
SEL-387-6 Relay
If no data are available, the relay replies:
"No Data Available","0668"<CR>
CTH Hourly Profile
Data Report
If H is specified in the command line, the report on hourly profile data is
provided. To obtain the report for Phase A, send the following:
CTH H 1 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
MONTH_","DAY_","YEAR_","HOUR_","MIN_","CommError","Ambient","Calc TopOil","Msrd
TopOil","Hot Spot","Load","FAA","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,"x",xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
To obtain the report for Phase B, send the following:
CTH H 2 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","CommError","Ambient","Calc TopOil","Msrd
TopOil","Hot Spot","Load", FAA",
,"yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,"x",xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
To obtain the report for Phase C, send the following:
CTH H 3 <Enter>
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>
MONTH_","DAY_","YEAR_","HOUR_","MIN_","ComError","Ambient","Calc TopOil","Msrd
TopOil","Hot Spot","Load","FAA","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,"x",xxxx,xxxx,xxxx,xxxx,xxxx,xxxx"yyyy"<CR>
…(previous line repeated until all archive data is listed)
<ETX>
If no data are available, the relay replies:
"No Data Available","0668"<CR>
CTH Temperature
Input Data Report
<STX>
"MONTH_","DAY_","YEAR_","HOUR_","MIN_","SEC_","MSEC_","yyyy"<CR>
xxxx,xxxx,xxxx,xxxx,xxxx,xxx,xxxx,"yyyy"<CR>
"Input#","Temp","yyyy"<CR>
xxxx,xxxx,"yyyy"<CR>
…(previous line repeated for each input available)
<ETX>
where:
xxxx = data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the checksum for the
line.
where:
xxxx = data values corresponding to the first line labels.
yyyy = the 4-byte ASCII representation of the checksum for the
line.
