3 Operation
3--9
F--9999--8 Build 8 Issue 1
DRIVE SPEED
Fig. 3-17. Main Drive Feed
3.2.3.15 SPEED -- Adjustment Control
Adjusts main drive motor speed. The dial is turned
clockwise to increase, and counterclockwise to
decrease the machine drive speed.
Note ! Drive speeds too low or too high will
cause improper machine operation.
COUNT RESET
COUNT SET
NUMBER
OF
SHEETS
RAN
COUNT SET
Fig. 3 -18. Feeder Counter
3.2.3.16 FEEDER COUNTER
Activating the Feeder Counter, allows operator to
specify an exact number of sheets to be run. The
feeder shuts off after the requirement has been
met.
The counter only counts when the machine is in
RUN mode and the Counter button is ON. The
digital counter counts forwards to the number
specified, then shuts feeder and vacuum OFF
when that number is reached.
● Do not change setting while counter is running.
