PID: Service component PID value
Type: Service and component encoding format
Bitrate: Individual current bitrate of services and components
When clicking a service, details about the service and service components will be displayed.
If a PID is scrambled this is indicated in the service tree by the color green or blue (for even and odd
scrambling respectively). A missing PID is indicated by the color red. If one of the blue PID links is
clicked, PID details are shown.
Click the Show thumbnail button to view a thumbnail of the selected service. Thumbnails can only be
shown for services that are not scrambled.
Service node
Service name: Name of the highlighted service, as signaled in SDT or VCT
Service ID: Service ID number
Service type: Service type as signaled in SDT
Service provider name:
The name of the service provider as signaled in SDT. Not applicable for
ATSC streams.
Current bitrate: The current bitrate measurement for this service. The bitrate is averaged
over 1 second.
Minimum bitrate:
The minimum bitrate measurement for this service since the start of the
monitoring period. (I.e. when the probe tuned to the frequency or when the
monitoring of this frequency was restarted by the user clicking on ‘Clear
status’ in the ‘ETR Overview’.)
Maximum bitrate:
The maximum bitrate measurement for this service since the start of the
monitoring period.
PMT PID: The service’s PMT PID
132 VB2xx GigE User’s Manual version 5.4
