DVB-T2 L1 Pre Information
T2 Version: DVB-T2 Version:
1.1.1
1.2.1
1.3.1
Post scrambling:
Informs if L1-Post scrambling is enabled, supported from DVB-T2
v1.3.1 ‘True’ or ‘false’.
DVB-T2 profile: Determines current profile of DVB-T2 Signal:
Base
Lite (supported form DVB-T2 v1.3.1)
Base compatible with Lite:
Indicates if the DVB-T2 Base Profile is compatible with DVB-T2 Lite
profile. If Base is incompatible with Lite one has to specify correctly
which profile should be used for tuning: Base or Lite. If there is com-
patibility between both DVB-T2 profiles the tuning will be successful
with any of them. ‘True’ or ‘False’
Type: The stream type contained within the current T2 super-frame.
TS (Transport stream only)
GS (Generic streams only)
Mixed TS and GS
The OFDM mode (DFT size). Possible OFDM modes are 1K, 2K, 4K,
8K, 16K and 32K
BW extended: Bandwidth extension indicator (only for 8K/ 16K/ 32K) True or False
S1: S1 Signaling. P1 S1
0 – SISO (Single input, single output)
1 – MISO (Multiple input, single output)
2 – Non DVB-T2
182 VB2xx GigE User’s Manual version 5.4
