(Bulb): The bulb indicates whether the data interface is connected and active or not.
IPv4 status: The IPv4 status as defined in the Setup — Ethernet view
IPv4 address:
The probe IPv4 Ethernet data/video interface IP address as defined by the user in
the Setup — Ethernet view
IPv4 netmask:
The probe IPv4 Ethernet data/video interface IP address as defined by the user in
the Setup — Ethernet view
Management interface
(Bulb):
The bulb indicates whether the management interface is connected and active or
not.
IPv4 status: The IPv4 status as defined in the Setup — Ethernet view
IPv4 address:
The probe IPv4 Ethernet data/video interface IP address as defined by the user in
the Setup — Ethernet view
IPv4 netmask:
The probe IPv4 Ethernet data/video interface IP address as defined by the user in
the Setup — Ethernet view
ETH info
Joined: The number of joined streams (multicasts and unicasts)
Unicasts: The number of unicasts currently being joined/monitored by the probe
Multicasts: The number of multicasts currently being joined/monitored by the probe
IGMP ver:
The IGMP version currently used by the probe. IGMPv2 is used unless the operator has
selected source specific multicasts (
Setup — Params
view), in which case IGMPv3 is
used.
VLAN tag:
The VLAN tag currently used by the probe. If no VLAN tag has been specified by the
operator (Setup — Params view), the VLAN tag value will read disabled.
ETH alarms per type
No signal: The number of currently active Ethernet ‘No signal’ alarms
CC skips: The number of currently active Ethernet ‘CC skips’ alarms
MLR>=thresh:
The number of currently active Ethernet MLR alarms, i.e. the total number of ‘MLR>=
warning-threshold’ and ‘MLR>= alarm-threshold’ alarms
IAT>=thresh:
The number of currently active Ethernet IAT alarms, i.e. the total number of ‘IAT>=
warning-threshold’ and ‘IAT>= alarm-threshold’ alarms
RTP alarms:
The number of currently active RTP alarms, i.e. the total number of ‘RTP packet
drop’, ‘RTP duplicates’ and ‘RTP out of order’ alarms
Other alarms:
The total number of currently active Ethernet alarms not included in the alarm figures
specified above
48 VB2xx GigE User’s Manual version 5.4
