5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 94
* Only fitted if the 5200 Multi Purpose includes 2 optional milliAmp outputs.
† Only fitted if the 5200 Multi Purpose includes 1 or 2 optional milliAmp outputs.
‡ Not fitted if the front sample gas outlet option was specified when you ordered
your Multi Purpose.
# Not fitted to a standard Multi Purpose with an internal sample pump.
Figure 2 - Rear of the Multi Purpose
Key Description Key Description
1.
2.
3.
Serial output port
Power inlet
milliAmp output socket 2 *
4.
5.
6.
milliAmp output socket 1 †
Sample gas outlet ‡
Bypass gas outlet #
