5200 Multi Purpose and 5200 Multi Purpose HF Gas Analysers
05230001A / Revision 9
3
* The legends on the labels show the sample gases for which the Multi Purpose is
configured.
† Only available if an internal sample pump is fitted.
‡ Only fitted if the front sample gas outlet option was specified when you ordered
your Multi Purpose.
Figure 1 - Front of the Multi Purpose
Key Description Key Description
1.
2.
3.
4.
5.
6.
7.
8.
Sample gas 1 label *
Sample gas 2 label *
Soft key 3
Soft key 4
Alarm LED (red)
Power On/Off key
Filter retaining cap
Sample gas inlet
9.
10.
11.
12.
13.
14.
15.
Sample gas outlet † ‡
Fault LED (amber)
Sample pump key †
Sample pump LED (green) †
Soft key 1
Soft key 2
Display
