Startup
DIP switches
Operating Instructions – MOVIMOT
®
advanced
108
DIP switch S1/3: Deactivating the speed monitoring
INFORMATION
If the function of this DIP switch is deactivated via parameter access, the last active
setting of the relevant parameter is maintained.
This DIP switch is used to disable speed monitoring.
• Speed monitoring OFF (S1/3 = ON): Speed monitoring is not active.
• Speed monitoring ON (S1/3 = OFF): Speed monitoring is active.
Speed monitoring is used to protect the drive in case of blockage.
When speed monitoring is active and the drive operates at the current limit for
longer than 1 second (factory settings), the drive unit triggers the fault "Speed
monitoring". The drive unit signals the fault, for example via the "DRIVE" status
LED. The current limit must be reached permanently for the duration of the delay
time before the monitoring function trips.
DIP switch S2/2: Source of setpoint f1
Use this DIP switch to select the source of the speed setpoint f1.
• Potentiometer f1 (S2/2 = OFF): The settings of potentiometer f1 define the speed
of the drive unit when setpoint f1 is active (see chapter "Startup" > "Control ele-
ments" > "Potentiometer f1").
• Analog input AI1 (S2/2 = ON): The value of analog input AI1 determined the speed
of the drive unit when setpoint f1 is active. (See chapter "Operation" > "Setpoint
scaling of the analog input".
25891936/EN – 05/2020
