6
Startup
DIP switches
Operating Instructions – MOVIMOT
®
advanced
107
6.5.2 Description of the DIP switches
DIP switch S1/1: Reversing the direction of rotation
INFORMATION
The direction of rotation is reversed depending on the setting of the DIP switch and of
the parameter drive train1 > Controller > Direction of rotation reversal. If both set-
tings are active, the speed setpoint is not inverted (logical XOR).
You can reverse the direction of rotation of the drive using this DIP switch.
• OFF (S1/1=OFF): The drive turns clockwise for a positive setpoint and counter-
clockwise for a negative setpoint.
• ON (S1/1 = ON): The drive turns counterclockwise for a positive setpoint and
clockwise for a negative setpoint.
DIP switch S1/2: Releasing the brake / deactivating DynaStop
®
with FCB01 – enable
WARNING
Risk from falling loads.
This can result in severe or fatal injuries.
• Do not enable the function "Releasing the brake / deactivating DynaStop
®
" for
hoist applications and applications with potentially falling loads.
INFORMATION
If the function of this DIP switch is deactivated via parameter access, the last active
setting of the relevant parameter is maintained.
Use this DIP switch to enable the function "Releasing the brake / deactivating
DynaStop
®
with FCB01" even when the drive is disabled.
• OFF (S1/2 = OFF): The function "Releasing the brake / deactivating DynaStop
®
with FCB 01" is inhibited.
• ON(S1/2=ON): The function "Releasing the brake / deactivating DynaStop
®
with
FCB 01" is enabled.
When the function block FCB 01 is active, you can release the brake or deactivate
DynaStop
®
using a digital input or an actuated process data bit.
INFORMATION
For more information about disabling DynaStop
®
without drive enable, refer to
chapter "Operation".
25891936/EN – 05/2020
