11
Technical data and dimension sheets
Technical data
Operating Instructions – MOVIMOT
®
advanced
238
Installation location
MOVIMOT
®
advanced
Ambient temperature See chapter "Environmental conditions"
Degree of protection IP Standard: IP65 according to EN60529 (housing closed and all cable
bushings sealed)
Pollution class 2 in accordance with IEC60664-1
Overvoltage category III in accordance with IEC60664-1
Installation altitude h Up to h ≤ 1000m without restrictions.
The following restrictions apply to altitudes >1000m:
• From 1000m to maximum 3800m: I
N
reduction by 1% per 100m
• From 2000m to maximum 3800m: To maintain protective separa-
tion and the air gaps and creepage distances in accordance with
EN61800‑5‑1, you have to connect an overvoltage protection
device in order to reduce the overvoltages from category III to cate-
gory II.
Proof of mechanical
strength
Class 3M5, 5M1 according to DINEN60721-3-3/-5
General information
MOVIMOT
®
advanced
No. of times power may be
switched on/off
1 × per minute
Minimum switch-off time for
Power off
10s
Operating mode S1, DB (EN 60034-1)
Type of cooling Natural cooling to DIN41751 and EN61800-5-1
Signaling functions Display elements to indicate the device state
Required preventive measure Grounding the device
Current carrying capacity of ter-
minals
See chapter:
• See chapter "Technical data and dimension sheets" > "Technical
data" > "Current carrying capacity of the terminals" in the operating
instructions.
• "Electrical Installation" > "Installation instructions" > "Permitted
cable cross section of terminals"
Interference immunity EN61800-3, 2. Environment (industrial environment)
Interference emission EN61800-3 category C3
With IT systems, no EMC category is specified.
Mass See chapter "Technical data and dimensions sheets" > "Technical
data" > "General technical data of MOVIMOT
®
advanced" > "Mo-
tor" (connection type W or m)
25891936/EN – 05/2020
