11
Technical data and dimension sheets
Braking resistors
Operating Instructions – MOVIMOT
®
advanced
248
Dimension drawing of BW150‑003/K-1.5
The following figure shows the dimensions of the external braking resistor
BW150-003/K-1.5:
110
146
10
6
60
15
15.5
80
98
4.6
Ø8
1500
25298773259
Dimension drawing of BW100‑005/K-1.5
The following figure shows the dimensions of the external braking resistor
BW100-005/K-1.5:
216
252
10
6
60
15
15.5
80
204
4.6
Ø8
1500
25298780043
25891936/EN – 05/2020
