5
Electrical installation
Installation instructions
Operating Instructions – MOVIMOT
®
advanced
41
5.3.5 Actuating line terminals X1a
Adhere to the following sequence when actuating the line terminalsX1a:
Line terminals X1a (the following figure shows a schematic illustration)
2.
1.
25649924107
5.3.6 Activating terminals X3 for the braking resistor
Adhere to the following sequence when you activate the terminals X3 for the braking
resistor:
Terminals X3 for the braking resistor (the following figure shows a schematic
illustration)
1.
2.
25650172171
25891936/EN – 05/2020
