Electrical installation
Terminal assignment
Operating Instructions – MOVIMOT
®
advanced
50
The following figure shows the factory-installed jumpers at the X9 terminals:
1 2 3 4
11 12 13 14
21 22 23 24
5 6
15 16
25 26
X9
29006177419
These jumpers are not present in the following designs:
• Designs with plug connectors with STO function.
For additional information, refer to chapter "Functional safety".
