5
Electrical installation
Plug connectors
Operating Instructions – MOVIMOT
®
advanced
60
Plug connectors Not together at a
position with the
plug connector:
Designation Coding ring/
color
Function Position
X2242 - AC 400 V connection (OUT) X, 2 or 3
• X1203_2
• X5136
X5504 Yellow STO (3-core connection)
3)
X, 2 or 3 –
X5505 Yellow STO (3-core connection)
3)
X, 2 or 3
• X4142
X5136 - Digital inputs/outputs X, 2 or 3
• X1203_2
• X2242
X4142 Black Engineering interface X, 2 or 3
• X5505
• X1524
- - [1] Optional pressure compensation X or 2 –
1) Plug connector X1203_1 can also be ordered individually (i.e. without plug connector X1203_2).
2) Plug connector X1206 can be ordered separately (i.e. without plug connector X2242).
3) Plug connectors X5504 and X5505 can only be ordered together.
25891936/EN – 05/2020
