Operating Instructions – Electronic Motor DRC.-..-SNI
147
10
Description of status and operating displays
Service
10.5.3 "RUN" LED
10.5.4 "DRIVE" status LED
RUN LED
LED
color
LED status Operating state Description
-Off Not ready No line voltage
→ Check supply cable and line voltage for interruption.
Yellow Flashing
steadily
Not ready Initialization phase
Green Flashing
steadily
Not ready Power section parameters are being loaded or firmware is being updated
Green Steady light Ready for
operation
System ready
Yellow Steady light Ready but unit
inhibited
"STO" signal detected, safe stop
→ Check voltage at STO terminal
Green/
yellow
With alter-
nating
colors
Ready but timeout Cyclical data exchange – communication interrupted (error 47 or 67).
→ No SBus/SNI connection between DRC inverter and controller. Check and estab-
lish connection, especially terminating resistor.
→ EMC influence Check shielding of data lines and improve, if necessary.
→ Protocol time between the individual telegrams is longer than the set time (timeout
interval). Shorten telegram cycle.
Red Steady light Error Possible errors:
• CPU error (17, 37)
• NV memory error (25)
• Error while transmitting parameters (97)
• IPOS error (10)
• Boot synchronization error (40, 41)
• Safety error (119)
→ More detailed diagnostic information via Drive LED.
DRIVE LED
LED color LED status Operating state Description
–Off Not ready No line voltage
Yellow Flashing steadily Not ready Initialization phase or line voltage not OK.
Yellow Flashing briefly at
regular intervals
Ready for operation In conjunction with mechatronic MOVIGEAR
®
drive
unit:
Deactivating DynaStop
®
without drive enable active
In conjunction with DRC electronic motor:
Brake release without drive enable signal active
Yellow Steady light Ready but unit inhibited Line voltage OK, output stage inhibited
Yellow 2 x flashing, pause Ready but manual mode/local
mode without unit enable
signal
Line voltage OK
Green/
yellow
With alternating
colors
Ready but timeout Communication interrupted during cyclical data exchange
(error 43, 46, or 47)
Green Steady light Unit enabled Motor in operation
Green Flashing evenly, fast Current limit active Drive operating at current limit
Green Flashing steadily Ready for operation Line voltage OK but no enable signal. Output stage is
energized.
Green/red With alternating
colors
Ready for operation Displayed error is pending. Output stage is energized.
Yellow/red With alternating
colors
Ready for operation Displayed error is pending. Output stage inhibited.
