Description of status and operating displays
Service
Red Steady light Error 40 Boot synchronization error
Error 41 Watchdog option error
Error 116 MOVI-PLC
®
timeout
Error 119 Safety error
Red Flashing slowly Error 08 Speed monitoring error
Error 26 External terminal error
Error 30 Emergency stop timeout error
Error 15 Encoder error
Error 16 Incorrect startup
Error 45 Initialization error
Incorrect motor/inverter assignment
Error 50 Internal voltage supply too low
Errors 17, 18, 37, 53 CPU error
Error 25 NV memory error
Error 27, 29 "Limit switch" error
Error 39 "Reference travel" error
Error 42 Positioning lag error
Error 94 Checksum error
Error 97 Parameter transmission error
Errors 10, 32, 77 IPOS error
Error 123 Positioning interruption error
Red 2x flashing, break Error 07 DC link voltage too high
Red 3x flashing, break Error 01 Overcurrent in output stage
Error 11 Overtemperature of heat sink or electronics
Red 4x flashing, break Error 31 TF trip
Error 44 Ixt utilization/UL monitoring
Error 52 Machine control error
Red 5x flashing, break Error 89 Only in conjunction with DRC electronic motor:
Overtemperature in brake
Red 6x flashing, break Error 06 Line phase failure
DRIVE LED
LED color LED status Operating state Description
