Operating Instructions – Electronic Motor DRC.-..-SNI
12
Braking resistors
Technical Data and Dimension Sheets
Dimension drawing
BW100-009-T
The following figure shows the dimensions of the external braking resistor
BW100-009-T:
4850322059
75
160
174 162
7
316
65
100
<435
ø7x11
