Operating Instructions – Electronic Motor DRC.-..-SNI
5
Plug connectors
Electrical Installation
5.9.5 Plug connector variant
M23 plug connectors are available in the following variants:
• [1] "Straight" plug connector variant
• [2] "Right-angle" plug connector variant
Once the mating connector has been plugged in, the "right-angle" connector can be
adjusted without using additional tools.
NOTICE
Possible damage of the right-angle connector in case of rotation without mating
connector.
Irreparable damage to the thread, damage to the sealing surface.
• Do not use pliers to adjust the right-angle connector before connecting it.
NOTICE
Adjusting the right-angle connector too often can damage it.
Potential damage to property
• Adjust the plug connector only when installing and connecting the drive unit.
• Do not turn the plug connector regularly once it has been installed.
