Operating Instructions – Electronic Motor DRC.-..-SNI
59
5
Plug connectors
Electrical Installation
5.9.4 Restrictions in conjunction with pressure compensation
The position for STO plug connectors is occupied by the pressure compensation fitting
[1] when using the optional design for use in wet areas (with
MOVIGEAR
®
)/ASEPTIC
plus
design (with DRC) and M5, M6 mounting position. In this
case, plug connectors for STO are not possible:
9007201700846347
