Operating Instructions – Electronic Motor DRC.-..-SNI
69
5
Assignment of optional plug connectors
Electrical Installation
Connection cables
The following table provides an overview of the cables available for this connection:
INFORMATION
Use only shielded cables for this connection and only suitable plug connectors that
connect the shield with the unit in an HF-capable manner.
Connection cable
Length/
Installation
type
Operating
voltage
Part number 1 812 496 8
Variable
DC 60 V
M12, 5-pole, A-coded M12, 5-pole, A-coded
Part number 1 812 740 1
Variable
DC 60 V
M12, 5-pole, A-coded M12, 5-pole, A-coded
