Operating Instructions – Electronic Motor DRC.-..-SNI
99
8
Overview of power section parameters
Parameters
8.3.2 Parameters that can be changed
Storage location
Setpoints/ramp generators
INFORMATION
The following parameters are stored in the DRC
motor.
If the motor is replaced, for example for service
purposes, changes made to these parameters must
be made again.
Index Parameter name Unit Meaning / value range
Power section parameters \ setpoints/ramp generators \ setpoint monitoring
Setpoint adjustment
8468.0 Setpoint filter 0.00 – 5.00
– 3000.00 [ms] 1 digit = 0.001 ms
Setpoint stop function
8578.0 Setpoint stop function • 0 = Off
•1 = On
8579.0 Stop setpoint 160
– 500 rpm 1 digit = 0.001 rpm
8580.0 Start offset – 0 – 30
– 500 [rpm] 1 digit = 0.001 rpm
Power section parameters \ setpoints/ramp generators \ speed ramps
Ramp generator 1
8470.0 Ramp t11 up CW 0.0 – 4.0
– 2000.0 [s] 1 digit = 0.001 s
8471.0 Ramp t11 down CW 0.0 – 4.0
– 2000.0 [s] 1 digit = 0.001 s
8472.0 Ramp t11 up CCW 0.0 – 4.0
– 2000.0 [s] 1 digit = 0.001 s
8473.0 Ramp t11 down CCW 0.0 – 4.0
– 2000.0 [s] 1 digit = 0.001 s
Stop ramps
8476.0 Stop ramp t13 0.0 – 2.0
– 2000.0 [s] 1 digit = 0.001 s
8477.0 Emergency stop ramp t14 0.0 – 2.0
– 2000.0 [s] 1 digit = 0.001 s
Ramp monitoring functions
8928.0 Ramp monitoring • 0 = Off
•1 = On
Power section parameters \ setpoints/ramp generators \ fixed setpoints
Fixed internal setpoints
8489.0 Fixed setpoint n11 -2000.0 – 150.0
– 2000.0 [rpm] 1 digit = 0.001 rpm
8490.0 Fixed setpoint n12 -2000.0 – 750.0
– 2000.0 [rpm] 1 digit = 0.001 rpm
8491.0 Fixed setpoint n13 -2000.0 – 1500.0
– 2000.0 [rpm] 1 digit = 0.001 rpm
