Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of power section parameters
Parameters
Drive data
NOTICE
Damage to the DRC drive unit.
Potential damage to property
• Consult SEW-EURODRIVE before you change the torque limit.
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ drive data \ motor parameters
Motor operating mode
8574.0 Operating mode (display value) • 16 = Servo
• 18 = Servo & IPOS
Motor direction of rotation
8537.0 Direction of rotation reversal • 0 = Off
•1 = On
Modulation
8827.0 PWM frequency • 0 = 4 kHz
•1 = 8kHz
Power section parameters \ drive data \ monitoring functions
Speed monitoring
8557.0 Speed monitoring • 0 = Off
• 1 = Motor mode
• 2 = Regenerative mode
• 3 = Motor/regenerative
8558.0 Speed monitoring delay time 0.00 – 1.00
– 10.00 [s] 1 digit = 0.001 s
Power section parameters \ drive data \ limit values
Setpoint limits
8516.0 Minimum speed 0.0 – 200.0
– 2000.0 [rpm] 1 digit = 0.001 rpm
8517.0 Maximum speed 0.0 – 200.0 – 2000.0
[rpm] 1 digit = 0.001 rpm
Drive limits
8518.0 Current limit In conjunction with
mechatronic MOVIGEAR
®
drive unit:
0 – 250
– 400 [%I
N
]
1 digit = 0.001 %I
N
In conjunction with DRC
electronic motor:
0 – 250
– 300 [%I
N
]
1 digit = 0.001 %I
N
9951.3 Effective current limit 0 – 400 [%I
N
] 1 digit = 0.001 %I
N
8688.0 Torque limit In conjunction with
mechatronic MOVIGEAR
®
drive unit:
0 – 250
– 400 [%I
N
]
1 digit = 0.001 %I
N
In conjunction with DRC
electronic motor:
0 – 250
– 300 [%I
N
]
1 digit = 0.001 %I
N
