Operating Instructions – Electronic Motor DRC.-..-SNI
101
8
Overview of power section parameters
Parameters
Terminal assignment
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ terminal assignment \ binary inputs
Binary inputs
8334.0, bit 0 Binary input DI00 status Fixed assignment: /controller inhibit
8334.0, bit 1 Binary input DI01 status [Bit field]
8334.0, bit 2 Binary input DI02 status [Bit field]
8334.0, bit 3 Binary input DI03 status [Bit field]
8334.0, bit 4 Binary input DI04 status [Bit field]
8335.0 Binary input DI01 function • 0 = No function
• 1 = Enable/Stop
• 2 = CW/stop
• 3 = CCW/stop
•4 = n11
• 5 = n12
• 8 = Speed ramp switchover
•9 = Reserved
• 10 = Reserved
• 11 = /External fault
• 12 = Error reset
• 13 = Reserved
• 14 = /Limit switch right
• 15 = /Limit switch left
• 16 = IPOS input
• 17 = Reference cam
• 18 = Reference travel start
• 19 = Slave free running
• 20 = Setpoint acceptance active
• 30 = /Controller inhibit
8336.0 Binary input DI02 function
8337.0 Binary input DI03 function
8338.0 Binary input DI04 function
Virtual binary inputs
8348.0, bit 0 Binary input DI10 status [Bit field]
8348.0, bit 1 Binary input DI11 status [Bit field]
8348.0, bit 2 Binary input DI12 status [Bit field]
8348.0, bit 3 Binary input DI13 status [Bit field]
8348.0, bit 4 Binary input DI14 status [Bit field]
8348.0, bit 5 Binary input DI15 status [Bit field]
8348.0, bit 6 Binary input DI16 status [Bit field]
8348.0, bit 7 Binary input DI17 status [Bit field]
8340.0 Binary input DI10 function • 0 = No function
• 1 = Enable/Stop
• 2 = CW/stop
• 3 = CCW/stop
•4 = n11
• 5 = n12
• 8 = Speed ramp switchover
•9 = Reserved
• 10 = Reserved
• 11 = /External fault
• 12 = Error reset
• 13 = Reserved
• 14 = /Limit switch right
• 15 = /Limit switch left
• 16 = IPOS input
• 17 = Reference cam
• 18 = Reference travel start
• 19 = Slave free running
• 20 = Setpoint acceptance active
• 30 = /Controller inhibit
8341.0 Binary input DI11 function
8342.0 Binary input DI12 function
8343.0 Binary input DI13 function
8344.0 Binary input DI14 function
8345.0 Binary input DI15 function
8346.0 Binary input DI16 function
8347.0 Binary input DI17 function
