Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of power section parameters
Parameters
Power section parameters \ terminal assignment \ binary outputs
Virtual binary outputs
8360.0, bit 0 Binary output DO10 status [Bit field]
8360.0, bit 1 Binary output DO11 status [Bit field]
8360.0, bit 2 Binary output DO12 status [Bit field]
8360.0, bit 3 Binary output DO13 status [Bit field]
8360.0, bit 4 Binary output DO14 status [Bit field]
8360.0, bit 5 Binary output DO15 status [Bit field]
8360.0, bit 6 Binary output DO16 status [Bit field]
8360.0, bit 7 Binary output DO17 status [Bit field]
8352.0 Binary output DO10 function • 0 = No function
• 1 = /Fault
• 2 = Ready
• 3 = Output stage ON
• 4 = Rotating field ON
• 5 = Brake released
• 6 = Brake applied
• 7 = Motor standstill
•8 = Reserved
• 9 = Speed reference signal
• 10 = Speed reference signal
• 11 = Setpoint-actual value comparison signal
• 12 = Current reference signal
• 13 = Imax signal
• 14 = /Warning motor utilization 1
• 19 = IPOS in position
• 20 = IPOS referenced
• 21 = IPOS output
• 22 = /IPOS fault
• 27 = STO – safe torque off
• 34 = Process data bit
8353.0 Binary output DO11 function
8354.0 Binary output DO12 function
8355.0 Binary output DO13 function
8356.0 Binary output DO14 function
8357.0 Binary output DO15 function
8358.0 Binary output DO16 function
8359.0 Binary output DO17 function
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
