Operating Instructions – Electronic Motor DRC.-..-SNI
103
8
Overview of power section parameters
Parameters
Diagnostic functions
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ diagnostics functions \ reference signals
Speed reference message
8539.0 Speed reference value 0.0 ... 1500.0 ... 2000.0 [rpm] 1 digit = 0.001 rpm
8540.0 Hysteresis 0.0 ... 100.0 ... 500.0 [rpm] 1 digit = 0.001 rpm
8541.0 Deceleration time 0.0 ... 1.0 ... 9.0 [s] 1 digit = 0.001 s
8542.0 Signal = "1" if: • 0 = n < n ref
• 1 = n > n ref
Speed window signal
8543.0 Window center 0 ... 1500 ... 2000 [rpm] 1 digit = 0.001 rpm
8544.0 Range width 0
... 2000 [rpm] 1 digit = 0.001 rpm
8545.0 Deceleration time 0 ... 1 ... 9 [s] 1 digit = 0.001 s
8546.0 Signal = "1" if: • 0 = inner
• 1 = external
Speed setpoint/actual value comparison
8547.0 Hysteresis 1 ... 100 ... 300 [rpm] 1 digit = 0.001 rpm
8548.0 Deceleration time 0 ... 1 ... 9 [s] 1 digit = 0.001 s
8549.0 Signal = "1" if: • 0 = n <> nset
• 1 = n = nset
Current reference signal
8550.0 Current reference value 0 ... 100 ... 400 [%] 1 digit = 0.001 %
8551.0 Hysteresis 0 ... 5 ... 30 [%] 1 digit = 0.001 %
8552.0 Deceleration time 0 ... 1 ... 9 [s] 1 digit = 0.001 s
8553.0 Signal = "1" if: • 0 = I < Iref
• 1 = I > Iref
Imax signal
8554.0 Hysteresis 5
... 50 [%] 1 digit = 0.001 %
8555.0 Deceleration time 0 ... 1 ... 9 [s] 1 digit = 0.001 s
8556.0 Signal = "1" if: • 0 = I = Imax
• 1 = I < Imax
