104
Operating Instructions – Electronic Motor DRC.-..-SNI
8
Overview of power section parameters
Parameters
Technology functions
Control functions
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ technology functions \ IPOS reference travel
8702.0 IPOS axis referenced (display value) • 0 = No
•1 = Yes
8623.0 Reference offset 0
– 2147483647
8624.0 Reference speed 1 0 – 200
– 2000 [rpm] 1 digit = 0.001 rpm
8625.0 Reference speed 2 In conjunction with DRC
electronic motor:
0– 50
– 2000 [rpm]
1 digit = 0.001 rpm
In conjunction with mechatronic
MOVIGEAR
®
drive unit:
0– 50
[rpm]
1 digit = 0.001 rpm
8626.0 Reference travel type • 0 = Left zero pulse
• 1 = Left end of reference cam
• 2 = Right end of reference cam
• 3 = Limit switch right
• 4 = Limit switch left
• 5 = No reference travel
• 6 = Reference cam flush with right limit switch
• 7 = Reference cam flush with left limit switch
8839.0 Reference travel to zero pulse • 0 = No
•1 = Yes
10455.1 Cam distance (display value) Increments [inc]
Index Parameter name MOVITOOLS
®
MotionStudio
Display
(Range / factory setting)
MOVILINK
®
scaling
Power section parameters \ control functions \ brake functions
8893.0 Activate "Brake release without drive enable" • 0 = No
•1 = Yes
8584.0 Brake function • 0 = Off
•1 = On
9833.20 Brake application for STO • 0 = No
•1 = Yes
