77
8012707/ZVF9/V2-1/2019-04 | SICK OPERATING INSTRUCTIONS | GM32
Subject to change without notice
SPECIFICATIONS 9
Fig. 42: Mounting flange DN125 (all dimensions in mm)
Fig. 43: Connection unit (all dimensions in mm)
ø 240
ø 178
ø 125
ø 133
14
240/500
8
18
4
5°
200
158
450
420
390
340
400
Ø 9
30
30
24
R = 4,5
