SICK S100 Standard User Manual

Operating instructions Chapter 8
S100
8012238/YY30/2015-02-20 © SICK AG • Subject to change without notice 41
Configuration
Byte Bit Description
0 0 State of control input A (S100 Professional only)
0: LOW
1: HIGH
0 1 State of control input B (S100 Professional only)
0: LOW
1: HIGH
0 2 State of control input C (S100 Professional only)
0: LOW
1: HIGH
0 3 State of control input D (S100 Professional only)
0: LOW
1: HIGH
0 4-6 Reserved
0 7 State of control input Stand-by mode
0: LOW
1: HIGH
1-7 0-7 Reserved
Tab. 14: Status of the virtual
inputs
(CAN Virtual Input State)
