10 SPECIFICATIONS
10.2.4 TRANSIC111LP inputs and outputs
10.2.5 Dimensions and mechanics
Power supply (nominal)
Allowed input range
24 VDC, 500 mA
11 … 36 VDC
Power input
maximum 6 W
Maximum power consumption
U
in
= 11 VDC
U
in
= 24 VDC
550 mA
250 mA
Analog output
Maximum load
Precision
Temperature dependence
0/4 … 20 mA, source
500 Ω
±0.05% of full-scale value
±0.005%⁄°C
Serial output (2-wire, not isolated) RS-485
Alarm/control relay 30 VAC , 1 A/ 60 VDC, 0.5 A
Serial output (NOTE: Only for maintenance) RS-232
Connections Screw terminals, 0.5...1.5 mm
2
RJ45 connection for RS-232
Resistance between signal ground and ground 10 MΩ
Dimensions (H × W × D) 306 × 184 × 74 mm
3
Weight 2.2 kg
Enclosure material G-AlSi10Mg (DIN 1725)
Enclosure classification IP66
Flange Can be attached to DIN/ANSI standard flanges.
Minimum flange sizes:
● DIN EN 1092 DN50: Fitted with M16 DIN 933 or similar
● ANSI ASME B16.5 (150) 2.5": Fitted with UNC 3⁄4"-10 or
similar
Cable bushing Cable gland M20×1.5
Conduit screw fitting 1⁄2" NPT
Filter Stainless steel mesh, holes 0.31 mm, wire thickness 0.2 mm
Hydrophobic PTFE filter, average pore size 8 μm
Materials with sample gas
contact
● AISI 316 L(1.4404)
● FKM or Kalrez
®
(optional)
● PTFE, SiN, MgF2, quartz
● Polymer coating
