8014084/ZWT7/V3-1/2020-06 | SICK OPERATING INSTRUCTIONS | TRANSIC111LP
Subject to change without notice
ADJUSTMENT 6
6 The adjustment starts. The following commands are now available for selection:
– Enter - output the most current measuring result
– R + Enter - continuous output of measuring results. Press Enter to stop the output
mode.
– Esc – to terminate the calibration
7 Wait until the measured value has stabilized. Enter the span gas concentration for the
first span and press Enter. The following is displayed after the command COXY2 has
been entered (example):
8 Now the second span gas has to be fed. Wait until the measured value has stabilized.
Enter the span gas concentration for the second span and press Enter. The new gain
and offset parameter values are now calculated and displayed.
9 It is possible that an error message can appear and new values are not calculated:
Error: Calibration points too close - Not calibrated
In this case, repeat the two-point adjustment with calibration gases that differ by at least
4vol% O2.
10 Enter command SAVE and confirm with Enter. The new values are stored in EEPROM.
11 Enter command ADJUST OFF and confirm with Enter. The adjustment is completed and
the measuring results are displayed again.
>coxy2
Customer calibration
Current condition/settings:
Pressure (bar) : 1.013
H2O (g/m3) : 0
CO2 (vol-%) : 0
Gas temperature (C) : 23.66
Internal temperature (C): 24.85
If parameters are not correct, cancel calibration with ESC and change parameters.
Connect ref gas #1 to cuvette
O2 (%): 20.99 Ref1 ?
O2 (%): 20.99 Ref1 ?
O2 (%): 20.99 Ref1 ?
O2 (%): 20.99 Ref1 ? 21
Connect ref gas #2 to cuvette
Output:
O2 (%): 10.05 Ref2 ?
O2 (%): 10.05 Ref2 ?
O2 (%): 10.05 Ref2 ?
O2 (%): 10.05 Ref2 ? 10
Calibration data:
Pressure setting (bar) : 1.013
Point #1
Measured oxygen : 20.99
Given oxygen : 21.00
Gas temperature (C) : 23.65
Ref path temperature (C): 24.84
Point #2
Measured oxygen : 10.05
Given oxygen : 10.00
Gas temperature (C) : 23.66
Ref path temperature (C) : 24.85
New Gain : 0.995
New Offset : 0.990
Calibration ready - remember SAVE command>save
>
>save
EEPROM (basic) saved successfully
EEPROM (op) saved successfully
EEPROM (op_log1) saved successfully
EEPROM (op_log2) saved successfully
>adjust off
Outputs to normal state
