10 SPECIFICATIONS
10.2 Technical data
10.2.1 Dimensions and bore patterns
Fig. 42: Wall bracket
The TRANSIC111LP configuration depends on the application.
Refer to the system documentation delivered with the TRANSIC111LP for the respective
configuration.
(4.84)
(4.05)
(0.39)
(4.25)
(2.05)
(3.23)
(2.44)
36 (1.42)19
(0.75)
(0.30)
All specifications in mm (inches)
1
1 = ø 6.5 mm, four pieces
