4 OPERATION
4.6 Serial interface commands
The serial interface commands are valid for the maintenance interface and the RS-485
interface.
4.6.1 List of serial interface commands
Element Significance Text style used
SAMPLE Name of the command or utility program UPPER CASE BOLD
{variable} Specifies several options from which the user
must select one, several or all options.
Lower case letters {in curly
brackets}
[option] Specifies optional elements. Lower case letters in [square
brackets]
. , : ; Punctuation marks are part of the command
and must be entered as such.
Lower case letters
<cr> Stands for pressing Enter (on the computer
keyboard)
Lower case letters
Table 3: Significance of command line elements
Property Description / value
Baud rate 19200
Data bits 8
Parity None
Stop bits 1
Table 4: Standard settings for the serial interface of the TRANSIC111LP
Serial interface command Description
? Display device information
?? Display device information with overwriting in POLL mode
ADDR Display/set device address
CALCS Display measuring parameters
CINFO Display calibration information
CLOSE Close serial interface (POLL mode)
DATE Display/set date
ECHO Set Echo mode
ERRS Display errors detected
FORM Set output format
HELP List commands
INTV Display/set continuous output interval
OPEN Open communication line
PARAM Display all changeable parameter values
PASS Output password
R Start continuous output
S Stop continuous output
SAVE Save parameters in EEPROM
SEND Send measuring results
SERI Display/set serial communication settings
Table 5: List of serial interface commands without password
