8014084/ZWT7/V3-1/2020-06 | SICK OPERATING INSTRUCTIONS | TRANSIC111LP
Subject to change without notice
OPERATION 4
4.14.4 Display calibration information (command CINFO)
Displays information from the last adjustment.
Syntax: CINFO<cr>
Example:
4.14.5 Display status of display range (command DB)
Displays the status of the display range.
Syntax: DB<cr>
Example:
4.14.6 List commands (command HELP)
Using this command without a parameter lists the commands accessible with the entered
password. Using the command with a command name as parameter displays a detailed
description of the respective command.
Syntax: HELP [Command]<cr>
Example:
Factory calibration:
Calibrated : 2009-11-24
Calib. text : Normal
Cal. point 1:
Given oxygen : 0.00
Gas temperature (C) : 20.81
Ref path temperature (C) : 21.90
Cal. point 2:
Given oxygen : 21.00
Gas temperature (C) : 20.81
Ref path temperature (C): 21.90
...
*** DISPLAY BOARD (DB) ***
Mode : NORMAL
State : NORMAL
Fault HW state : OFF
Display state : O2
Red led : OFF
Green led : SLOW
Relay : CLOSE
RELAY_MODE : FAULT_ALARM
LO POINT (%02) : 10.0
HI POINT (%02) : 11.0
...
Com-
mand
= Name of the desired command
>help
? Prints information about the device
?? Prints information even in POLL mode
.
.
>
