8014084/ZWT7/V3-1/2020-06 | SICK OPERATING INSTRUCTIONS | TRANSIC111LP
Subject to change without notice
OPERATION 4
4.10.3 Set carbon dioxide content for compensation (command CO2)
Use the SAVE command to store the setting in EEPROM, see “Save parameters (command
SAVE)”, page 58. Allowable range is 0 ... 100 vol% CO
2
.
Syntax: CO2 [Carbon dioxide]<cr>
0511-088
Example:
4.10.4 Set several/all ambient parameters with one single command (command ENV)
Syntax: ENV [Pressure] [Water] [Carbon dioxide]<cr>
Example:
The ENV command without parameters displays the current values for ambient parameters
and allows entering new values. Press Enter to confirm the current setting.
4.10.5 Calibrate analog output (command ICAL)
Calibrates the current output. Calculates and sets the values for parameters Gain (GI) and
Offset (OI).
Syntax:
ICAL<cr>
Example:
Carbon dioxide = CO
2
concentration in measured gas (vol% CO
2
)
>co2 10
CO2(%) : 10 ?
Pressure = Pressure setting (bar(a))
Water = Water content in measured gas (g/m
3
H
2
O)
Carbon diox-
ide
=CO
2
concentration in measured gas (vol% CO
2
)
>env
PRESSURE(bar) : 1.013 ?
H2O (g/m3) : 0 ?
CO2 (vol%) : 0 ?
>
Set pressure 1.000 bar(a), water content 50 g/m3 and CO2 content 20 vol% CO2:
>env 1 50 20
PRESSURE(bar) : 1.000
H2O (g/m3) : 50
CO2 (vol%) : 20
>
>ical
Ilow (mA) ? 3.42
Ihigh (mA) ? 17.6
>
