OPERATION 4
4.12 Checking the analog output
4.12.1 Set test current for analog output (command ITEST)
Starts and stops the mode for checking the current output.
Syntax:
ITEST [Current]<cr>
Example:
4.13 Relay operation
4.13.1 Display/set relay operating mode (command RELAY_MODE)
Sets the relay operating mode, see “Display/set relay operating mode (command RELAY_-
MODE)”, page 53.
Syntax: RELAY_MODE [warn-alarm / fault_alarm / high_open / low_open]<cr>
4.13.2 Display/set relay switching point (command RSEL)
Sets the relay switching points.
Syntax: RSEL<cr>
Example:
Where
current = test current (mA)
>itest 4
Test current set to 4 mA. Use ITEST to stop Test mode.
>itest
Current Test mode stopped.
>
warn_alarm = Relay open when maintenance request exists for error
fault_alarm = Relay open when error exists
high_open = Relay open when measuring result above upper point
Relay closed when measuring result below lower point
low_open = Relay open when measuring result below lower point
Relay closed when measuring result above upper point
NOTICE:
The contact relay is momentary.
>rsel
LO POINT (%02) : 10.0 ?
HI POINT (%02) : 11.0 ?
