4 OPERATION
4.14.7 Display status of laser temperature controller (command LTC)
Displays the status of the laser temperature controller with the associated variables.
Syntax: LTC<cr>
Example:
4.14.8 Display output status (command OUT)
Displays the status and settings of the analog output controller and the associated vari-
ables.
Syntax: OUT<cr>
Example:
>ltc
*** LASER TEMPERATURE CONTROLLER (LTC) ***
Mode : ON
State : TEMP_OK
Set Temp (C) : 29.074
Temp (C) : 29.073
Diff (C) : -0.001
PID Output : -773
DAC Output : 29227
>out
*** ANALOG OUTPUT (OUT) ***
Mode : NORMAL
State : NORMAL
Oxygen (%) : 0.00
Current (mA) : 3.00
DAC Output : 50000
GI : 1.0000
OI : 0.0000
NONFATALI (mA) : 3.000
FATALI (mA) : 3.000
I4 : 1
OUTMAX02 (%) : 20.000
OUTMIN02 (%) : 0.000
