SICK TRANSIC111LP - Display Measuring Status (Command MEA); Display Status of Serial Maintenance Interface (Command SCI1); Display Status of Serial RS-485 Interface (Command SCI2); Format Measuring Results (Command FORM)

45
8014084/ZWT7/V3-1/2020-06 | SICK OPERATING INSTRUCTIONS | TRANSIC111LP
Subject to change without notice
OPERATION 4
4.7.9 Display status of serial maintenance interface (command SCI1)
Displays and sets the status of the maintenance interface with the associated variables.
Syntax: SCI1<cr>
Example:
4.7.10 Display status of serial RS-485 interface (command SCI2)
Displays the status of the serial RS-485 interface with the associated variables.
Syntax: SCI2<cr>
Example:
4.7.11 Display measuring status (command MEA)
Displays the measurement status with the associated variables.
Syntax: MEA<cr>
Example:
4.7.12 Format measuring results (command FORM)
Configures the output format for the commands SEND, see “Send measuring results (com-
mand SEND)”, page 42 and R, see “Start continuous output (command R)”, page 42, and
can therefore also be changed as required.
Syntax:
FORM [x]<cr>
The formatting string comprises the data to be shown and the associated formatting
commands.
>sci1
*** SERVICE INTERFACE (SCI1) ***:
Mode : STOP
Seri : 19200 8 NONE 1
SERI : 19200 8 NONE 1
ECHO : ON
SMODE : STOP
>sci2
*** SERVICE INTERFACE (SCI2) ***:
Mode : STOP
Seri : 19200 8 NONE 1
SERI : 19200 8 NONE 1
ECHO : ON
SMODE : STOP
>mea
*** OXYGEN MEASUREMENT (MEA) ***
Mode : NORMAL
State : PEAK_SEARCH
OP (DAC/mA) : 20960 / 1.92
...
X = Formatting string
