6 ADJUSTMENT
6.3.3 One-point adjustment via the serial interface (command COXY1)
This adjustment calculates and sets a new gain or offset parameter value (depending on
the reference concentration used).
1 Enter the password, see “Entering the password (PAS)”, page 37.
2 The analog output can be held during an online adjustment with the command ADJUST
ON.
Input:
3 When adjustment conditions (gas pressure, humidity and CO
2
concentration) are
different from the operating conditions of the measuring device, set the ambient
parameters of the measuring device to the adjustment environment for the adjustment
duration. These settings must then be changed back to represent the process
conditions when the TRANSIC111LP is reinstalled in its operating environment. Further
information on setting the ambient parameters of the TRANSIC111LP can be found in
Section 5.
4 Enter command COXY1 and confirm with the Enter button.
5 Connect the gas inlet and let the gas flow in.
6 The adjustment starts. The following commands are now available for selection:
– Enter - output the most current measuring result
– R + Enter – continuous output of measuring results. Press Enter to terminate output
mode.
– Esc – to terminate the calibration
7 Wait until the measured value has stabilized. Enter the span gas concentration and
press Enter. The new gain or offset parameter value is calculated and displayed.
The following is displayed after entering the command COXY1:
8 Now enter command SAVE, see “Save parameters (command SAVE)”, page 58, and
press Enter. The new values are stored in EEPROM.
>adjust on
Outputs (analog, relay, POLL/Run and MT300) frozen
>coxy1
Customer calibration
Current condition/settings:
Pressure (bar) : 1.013
H2O (g/m3) : 0
CO2 (vol%) : 0
Gas temperature (C) : 23.64
Internal temperature (C): 24.84
If parameters are not correct, cancel calibration with ESC and change parameters.
Connect ref gas to cuvette.
Connect ref gas to cuvette.
O2 (%): 20.52 Ref ?
O2 (%): 20.51 Ref ?
O2 (%): 20.51 Ref ?
O2 (%): 20.51 Ref ? 20.50
Calibration data:
Pressure setting (bar) : 1.013
Measured oxygen : 20.51
Given oxygen : 20.50
Gas temperature (C) : 23.65
Ref path temperature (C) : 24.85
New Gain : 1.000
Calibration ready - remember SAVE command
>save
>save
EEPROM (basic) saved successfully
EEPROM (op) saved successfully
EEPROM (op_log1) saved successfully
EEPROM (op_log2) saved successfully
