6 ADJUSTMENT
The calibration starts. The following commands are now available for selection:
– Enter - output the most current measuring results or terminate continuous Print mode
– R + Enter - continuous output of measuring results with an interval of about 1 second.
Press Enter to terminate Print mode.
– Esc – to terminate the calibration
5 Wait until the measured value has stabilized. Enter the span gas concentration and
press Enter.
The new gain or offset parameter value is calculated and displayed.
The following is displayed after entering the command COXY1:
6 Enter command SAVE and press Enter. The new values are stored in EEPROM.
7 Enter command ADJUST OFF and press Enter.
>coxy1
Customer calibration
Current condition/settings:
Pressure (bar) : 1.013
H2O (g/m3) : 0
CO2 (vol-%) : 0
Gas temperature (C) : 23.64
Internal temperature (C): 24.84
If parameters are not correct, cancel calibration with ESC and change parameters
Connect ref gas to cuvette.
O2 (%): 20.52 Ref ?
O2 (%): 20.51 Ref ?
O2 (%): 20.51 Ref ? 20.50
Calibration data:
Pressure setting (bar) : 1.013
Measured oxygen : 20.51
Given oxygen : 20.50
Gas temperature (C) : 23.65
Ref path temperature (C) : 24.85
New Gain : 1.000
Calibration ready - remember SAVE command
>save
>save
EEPROM (op) saved successfully
EEPROM (op_log1) saved successfully
EEPROM (op_log2) saved successfully
>adjust off
Outputs to normal state
The adjustment is finished and the output returns to displaying the measurement
results.
