9410 series Communications
If your meter receives an incorrect community string, it generates an
AuthenticationFailure trap.
System strings
A system string is a text string which can be configured to provide information about
your meter.
There are three system strings on your meter:
System contact: enter the name of the SNMP system administrator.
System name: enter a descriptive name for your meter.
System location: enter a description of your meter’s location.
SNMP trapping implementation
Generic SNMP traps supported by your meter are:
Coldstart: the meter (SNMP agent) is starting.
Linkup: the SNMP agent is enabled.
AuthenticationFailure: the meter (SNMP agent) has received an incorrect
community value.
Enterprise-specific SNMP traps supported by your meter are:
Low: trap of events with a low event priority.
Medium: trap of events with a medium event priority.
High: trap of events with a high event priority.
Trap Event priority range
Low 64–127
Medium 128–191
High 192–255
NOTE: The number of events or maximum time delay settings only apply to
enterprise SNMP traps.
See the ION Reference, available from www.usa.siemens.com/pds, for detailed
information on the SNMP Mapping, SNMP Options and Alarm Options modules.
Default SNMP mapping
Enabling SNMP provides SNMP access to the meter values linked to the SNMP
Mapping module.
You can configure the SNMP Mapping module to link to different meter values. By
default, the following meter values are linked to the SNMP Mapping module:
I a kVAR tot Vll ca Vln avg Ib mean kW sd mx del-
rec
I b kVA tot Vll avg Freq Ic mx kW sd del
I c PF sign tot Vln a Ia mx Ic mean kW sd rec
I avg Vll ab Vln b Ia mean kW sd mx del kW sd del-rec
kW tot Vll bc Vln c Ib mx kW sd mx rec kVAR sd mx
del
kVAR sd mx
rec
kVAR sd mx
del-rec
kVAR sd del kVAR sd rec kVAR sd del-
rec
kVA sd mx del
88 7EN05-0336-03
